Super Light Digital Oscilloscope DHO802 DHO804 DHO812 DHO814 DHO824 2 Channel, 4 Channel 70MHz 100MHz 200MHz, 1.25GSa/S
Product Features
• Ultra-low noise floor, purer signal, never miss the small signals
• Up to 12 bits resolution for all the models of this series
• Max.analog bandwidth of 100 MHz, 4 analog channels, external trigger output(std.)available for the dual-channel model
• Max.real-time sample rate of 1.25 GSa/s
• Max.memory depth of 25 Mpts
• Vertical sensitivity range: 500 μV/div to 10 V/div
• Max.capture rate of 1,000,000 wfms/s (in UltraAcquire mode)
• Digital phosphor display with real-time 256-level intensity grading
• Waveform search and navigation function allows you to debug the signalanomalies faster• 7" (1024x600) capacitive multi-touch screen
• Brand new Flex Knob brings user-friendly experience
• USB Device & Host, LAN, and HDMI interfaces (std.)for all the models of thisseries
• Novel and delicate industrial design, easy to operate
• Unique online upgrade
Overview of theDHO800 Series Technical Specifications
OverviewoftheDHO800SeriesTechnicalSpecifications
Model |
DHO802 |
DHO804 |
DHO812. |
DHO814 |
Analog Bandwidth(-3dB) |
70 MHz |
100MHz |
||
|
Rise Time (10%to90%,typical) |
≤5ns |
≤3.5ns |
||
Number of Analog Channels |
2+EXT |
4 |
2+EXT |
4 |
SamplingMode. |
Real-time Sampling |
|||
|
Max.Sample RateofAnalog Channel |
Two-channelmodel: 1.25GSa/s(single-channel),625MSa/s(full-channel) 1.25GSa/s(single-channel),625MSa/s(dual-channel),312.5MSa/s(full-channel) |
|||
|
Max.Memory Depth |
Two-channelmodel: 25Mpts(single-channel),10Mpts(full-channel)four-channelmodel: 25Mpts(single-channel),10Mpts(dual-channel),1Mpts(full-channel) |
|||
Max.WaveformCapture Rate |
30,000wfms/s (Vector Mode) 1,000,000wfms/s(UltraAcquireMode) |
|||
Vertical Resolution |
12bits. |
|||
Hardware Real-timeWaveform Recordingand Playing |
Max.500,000 frames |
|||
Peak Detection |
Capture1.6 nsglitches |
|||
LCD Size and Type |
7"capacitive multi-touch screen |
|||
Display Resolution |
1024x600 |
|||
